Experiments

Biomechanical characterization of brain tissue

Biomechanical testing of ultrasoft tissues such as brain tissue is challenging as the response highly depends on length and time scales, the loading mode, strain and strain rate, or drainage conditions. Our goal is to establish an experimental procedure that minimizes falsifying effects, but also sufficiently covers loading scenarios relevant for real-life applications. We complement rheological, nanoindentation, and atomic force microscopy experiments performed at the LTM, FAU, with triaxial biomechanical testing at the Institute of Biomechanics, TU Graz, led by Prof. Gerhard A. Holzapfel, to thoroughly characterize animal and human brain tissue. Hand in hand with the mechanical modeling, we optimize the experimental procedures to assess the information required to establish realistic constitutive models and accurately calibrate the corresponding material parameters.
In addition to native brain tissue, we investigate biopolymeric substitute materials in collaboration with the Chair of Biomaterials, FAU, led by Prof. Aldo Boccaccini and the Biophysics group, FAU, led by Prof. Ben Fabry, see also [Link].

Real-time visualization of cellular responses to mechanical loading

Cellular behavior and function are significantly influenced by mechanical stimuli, including the mechanical properties of their environment and forces exerted on them, which can lead to local tissue deformation and potential damage. In order to better understand how mechanical load is transferred from the tissue to the cellular level, we have combined, for the first time, a rheometer for multi-modal large-strain mechanical measurements with a customized multiphoton microscope for simultaneous imaging. This new setup allows for real-time monitoring of cellular behaviors, such as dysfunction or death, in in their 3D environment, including tissue or in vitro systems, such as 3D cell cultures or organoids. This approach aims to enhance our understanding of mechanically induced cellular responses and identify 3D thresholds for mechanics-induced tissue and cell damage under multi-modal loading.

Spherical indentation for biomechanical tissue characterization

To probe the ultrasoft mechanical signature of brain and spinal cord tissue, we employ a spherical indentation setup. Spherical indenters with radii ranging from 3 to 250 µm are used, and experiments are conducted over a range of loading rates to capture the mechanical response of the tissue under force-, indentation-, or displacement-controlled conditions. A customized camera system enables precise localization of measurement sites, while a temperature-controlled Petri dish heating system maintains ambient conditions representative of the in vivo environment. Together, this setup allows micro- and mesoscale mechanical characterization of soft tissues and supports the quantification of both hyperelastic and viscoelastic material properties.

Analysis of the correlation between mechanics and microstructure

To obtain a basis for microstructurally motivated constitutive and evolution laws for brain tissue, we analyze the microstructure of mechanically tested specimens through histological staining, immunohistochemistry, and immunolabeling in collaboration with the Chair of Anatomy, FAU, led by Prof. Friedrich Paulsen. Our goal is to identify the microstructural components dominating the macroscopically recorded tissue response. A rheometer equipped with a microscope module allows us to track individual microstructural components such as cell nuclei during mechanical loading, as illustrated in Figure 1.

Analysis of the evolution of properties during development, homeostasis, and disease

In addition to the characterization of brain tissue behavior at a certain point in time, we aim to understand the evolution of properties during development, homeostasis, or disease. Through novel experimental procedures, we quantify how both mechanical properties and structure change with time – autonomously or induced by mechanical load. Swelling experiments as illustrated in Figure 1, for instance, allow us to reproduce the evolution of the macroscopic structure of our brain.
